Farm Machinery/Agricultural Machine

Weifang Shengchuan Machinery Co.,Ltd | Updated: Aug 27, 2016


Product Detail


  • Type:Portable Harvester

  • Application:Rice, Wheat

  • Power Source:Diesel

  • Harvest method:Cutting

  • Drive Type:Gear Drive

  • Transmission:Soft Shaft

  • Portable Harvester Type:Self-Propelled Harvester

  • Certification:ISO9001:2008, CE

  • Color:Green

  • Condition:New

  • Application Field:Agriculture

  • Trademark:YFM

Product Description

Specification

Model4.0L-0.6
Harvesting Capacity≥0.05 hm2/h
Overall Dimensions(LxWxH)2450*1260*1550mm
Weight330kg
Engine
Model188F
Rated Power10hp/7.5kw
Diesel engineSingle cylinder,air cooling,direct injection
Rated Engine Speed3600r/min
Header
Cutting Width1100mm
Min.ground clearance120mm
Feeding Capacity0.6kg/s
Fuel Consumption≤30kg/hm2
Type if LiftingHydraulic
CleaningSieving+winnowing+Suction
Impurity Rate≤2.0%
Broken RateWheat≤0.8%,rice ≤1%
Loss RateWheat≤0.8%,Rice≤1.2%


New threshing mechanism, bigger area of threshing and separation, clean threshing effect.
* New cleaning mechanism, double fans and sieves, much cleaner.
* Lower ground pressure, better for passing in paddy field.
* Big width conveyor device with new lifting system can provide a more efficient feeding and a higher lifting level.
