Managed Ethernet Switch with 2 Fiber Ports & 6 Ethernet Ports

Weifang Shengchuan Machinery Co.,Ltd | Updated: Sep 17, 2016

Product Details



Key Specifications/Special Features:

Overview
NT-M2600 is an L2 Web-smart media converter with switch function
With 1.6Gbps non-blocking switch fabric, 1K MAC address table and 802.3x Full-duplex flow control, the NT-M2600 offers wire-speed packet transfer performance without risk of packet loss
2 100Base-FX fiber ports extend the transmission distance of network up to 100km
For efficient management, with its built-in web-based management, the NT-M2600 offers an easy-to-use and configuration facility
Via the WEB interface the NT-M2600 can be programmed for basic switch management functions such as per port speed duplex settings, VLAN, QOS, broadcast storm and bandwidth control to enhance bandwidth utilization

Features

  • 155M at fiber port, 10/100/M self-adaptive at Ethernet ports, Half/Full-duplex self-adaptive

  • About 1K MAC address capacity, update automatically

  • Support broadcast storm protection

  • The max-rate data transmission (wire-speed): 148 800 frm/s (100M), 14,880 frm/s (10M)

  • Support 1552 byte VLAN data frame transmission (hardware configuration: 1552/1536 byte)

  • Support dividing into 16 groups VLAN, support QoS & port blocking

  • Support store-and-forward working mode, support half/full Duplex, support 802.3x flow control under full duplex working mode, support auto-sensation of MDI/MDIX

  • Support filter/forward special DA option

  • Network line status LED: transmission rate indicator (10/100M) fiber and twisted-pair's connection status

  • Support 8-level bandwidth control: 128K, 256K, 512K, 1M, 2M, 4M, 8M, full speed

  • Support 6 Ethernet ports communications simultaneously, using for connecting NIC, switch, and HUB

  • Support the IEEE802.1q, which can guarantee the backbone features of most mainstream products, such as inter-switch's VLAN function

  • High-capacity network caching technology ensures data transmission and multimedia applications

  • Non-blocking switch, ensuring data-transmission's security and stability

ParameterSpecifications
Standard
Port6-port RJ45 (100Base-TX), 2-port SC, ST, FC, or SFP (100Base-FX)
LED IndicatorPOWER: Green light
LINK/ACT: Green light, indicator for data transmission, showing fiber or Twisted Pair's connection status;
          Light off indicates fiber or Twisted Pair no-connection
          Light on indicates fiber or Twisted Pair normal connection
          Light blink indicates the data is transmitting at Ethernet/fiber  port
10/100M: Green light, Indicator for Ethernet or fiber port transmission rate
          Light off indicates transmission rate is 10M
          Light on indicates transmission rate is 100M
Switch mechanism Store and Forward
Power supplyPower Adapter: 5V, 10W
Operating temperature0-60℃
Maintaining temperature-40-70℃
Humidity5%-90% non-condensing
Dimension95mm(W)×30mm(D)×170mm(H) (shell thickness 1mm)

Primary Competitive Advantages:

  • Service

  • Small Orders Accepted

  • Brand-name Parts

  • Country of Origin

  • Distributorships Offered

  • Electronic Link

  • Experienced Staff

  • Guarantee/Warranty

  • International Approvals

  • Military Specifications

  • Packaging

  • Price

  • Product Features

  • Product Performance

  • Prompt Delivery

  • Quality Approvals

  • Reputation


Main Export Markets:

  • Eastern Europe

  • Mid East/Africa

  • North America

  • Western Europe

  • Asia

  • Australasia

  • Central/South America


Payment Details:


  • Payment Terms:Telegraphic Transfer (TT,T/T)


  • Minimum Order:1        Pieces

Delivery Details:
