Tillage Collision Avoidance Camera System with Quad Monitor

Weifang Shengchuan Machinery Co.,Ltd | Updated: Sep 23, 2016

Product Details


Key Specifications/Special Features:

  • Description:

    • With 7-inch digital screen TFT monitor OSD menu separately set each camera

    • Reversing image delay, priority of reverse camera and automatic switch display mode

    • Aluminum shell IP69K waterproof backup size

    • Aluminum shell waterproof IR side CCD camera for caravan

  • Specifications:

    • Up/down: 45/65°

    • Left/right: 65/65°

    • NTSC: 510 x 492 pixels

    • PAL: 500 x 582 pixels

    • Image type: 1/3-inch color Sharp CCD

    • Horizontal resolution: 420TVL

    • Effective pixels:

    • Usable illumination: 0lux (built-in 10-piece IR LED for picture support in dark)

    • Free viewing angle: 130°

    • Waterproof: IP69K

    • Shockproof: 10G

    • Video output: 1.0Vp p, 75Ω

    • Power supply: 12V DC from reversing monitor

    • Dimensions: 74 x 49 x 57mm (without mounting)

    • 7-inch digital screen TFT LCD color quad monitor with removable sun visor

    • Single, split and quad image view are selectable

    • OSD menu separately set each camera trigger priority and reversing image delay time: 0 to 30 seconds

    • OSD menu separately set each camera mirror and normal image

    • Manual and automatic switch display mode

    • Color system: PAL/NTSC (automatic)

    • Display resolution: 2,400 x 480 dots

    • Supports four camera input: 1.0Vp-p, 75Ω

    • Wide viewing angle (CR>10):

    • Brightness: 300cd/m² (automatically adjust environment by according)

    • Contrast ratio: 500:1

    • Backlight single LED

    • Operating temperature: -20 to +70°C

    • Storage temperature: -30 to +80°C

    • Free operating voltage: 11 to 32V DC (one cable solution)

    • External dimensions: 185 x 124 x 48mm (without mounting)

    • Weight: 379g (approximately)

  • Applications:

  • Large trucks, farm tractors, cleaning vehicles, mining vehicles, diggers and heavy plants

Main Export Markets:

  • Eastern Europe

  • North America

  • Mid East/Africa

  • Central/South America

  • Asia

  • Western Europe

  • Australasia


Payment Details:


  • Payment Terms:T/T in Advance, L/C at Sight
