Tillage Rear-view System with PAL/NTSC Color System

Weifang Shengchuan Machinery Co.,Ltd | Updated: Sep 23, 2016

Product Details




Key Specifications/Special Features:

  • 2.4GHz wireless transmission farm CCTV camera (model:DF-8073FS):

  • Built-in 2.4GHz transmitter

  • Image type: 1/3 inch color sharp CCD

  • Horizontal resolution: 420TVL

  • Resolution pixels:

  • NTSC (H x V): 510 x 492

  • PAL (H x V): 500 x 582

  • Usable illumination: 0 lux (built-in 18 pieces of IR LEDs for night vision (10M))

  • Free viewing angle: 130°

  • Waterproof: IP68

  • Shockproof: 10G

  • Transmission power: 10mW (estimate of 100 meter wireless send distance without block)

  • Operating temperature: -10 to 50°C, 95% RH

  • Storage temperature: -20 to 60°C, 95% RH

  • Power supply: 11 to 24V DC (from monitor)

  • Dimensions (W x H x D): 89 x 53 x 48mm (without mounting)

  • Weight: 200g

  • 7-inch TFT LCD 2.4GHz wireless monitor (model: SP-726):

  • With removable sun visor

  • Built-in 4-channel 2.4GHz wireless receive

  • 4-image switch automatically, shift time 0 to 30 seconds

  • Auto mirror image video when reversing

  • Color system: PAL/NTSC

  • Display resolution (H x V): 800 x 480 x RGB dots

  • Wide viewing angle (CR>10):

  • Up/down: 50/70 degrees

  • Left/right: 70/70 degrees

  • Brightness: 300cd/m2

  • Contrast ratio: 500:1

  • Operating temperature: -20 to 70°C

  • Storage temperature: -30 to 80°C

  • Power supply: 11 to 32V DC

  • External dimensions (L x W x T): 180 x 118 x 23mm

  • Weight: 239g

Main Export Markets:

  • Eastern Europe

  • North America

  • Mid East/Africa

  • Central/South America

  • Asia

  • Western Europe

  • Australasia


Payment Details:


  • Payment Terms:T/T in Advance, L/C at Sight
