Tractor Driven Rotary Tillage Machine

Weifang Shengchuan Machinery Co.,Ltd | Updated: Sep 07, 2016


Product Detail



Basic Info

  • Model NO.:RBR

  • Type:Rotary Tiller

  • Application Field:Agriculture

  • Farming Policy:Dry Cultivating Machinery

  • Power Source:Tractor

  • Operation:Continuous Running Operation, Soil Preparation Machinery

  • Traction Type:Hanging

  • Drive Type:Gear Drive

  • Arbor Configuration:Vertical Shaft

  • Color:Red

  • Apply to:Hard and Soft Soil

  • Trademark:RB

  • Origin:China

Product Description

RAINBOW MACHINERY CO., LTD
Agricultural rotary tiller machine

Rotary Tiller is driven by the tractor's out-put shaft.
During operation, the soil is crumbled by the rotating and forwarding of the blades fixed on the shaft.
It also can be used as shallow tilling and covering on the Stalinized soil to prevent the salt in the soil.
The machine will fulfill the working of cleaning stubbles and weeds, turning and covering green fertilizer
And preparing vegetable fields, etc.

Technical parameter of rotay tiller

ModelRBR-100RBR-125RBR-140RBR-160RBR-180RBR-200RBR-220RBR-250
Matched power  (Hp)12-1515-1820-3030-4050-5555-758075-80
Weight(kg)

192200220240405420435450
Working width (mm)10001250140016001800200022002500
Working depth
(mm)
Dry soil 8-148-1412-1812-1812-188-1412-1812-18
Paddy field10-1610-1614-2014-2014-2010-1614-2014-20
NO.of blades2224303850545862
Out size (mm)850*1050*950900*1310*1000900*1600*1000900*1880*10001020*2056*11521020*2396*11521020*2636*11521020*2816*1152
