Wheat Harvester / Small Size Wheat Combine

Weifang Shengchuan Machinery Co.,Ltd | Updated: Aug 27, 2016


Product Detail


Weifamg Shengchuan Machinery C0., LTD

abby yang:

wechat: 1304061398

whatsapp: +8615169566796

skype: abbyyang 111

mobile: 008615169566796

email:ay@shengchuanmachie.com


  • Model NO.:4LZ-1.5

  • Type:Horizontal Cut Harvester

  • Application:Wheat

  • Power Source:Diesel

  • Application Field:Agriculture

  • Modle:4lz-1.5

  • Size:Wheel Type Self-Propelled

  • Cutter Width:1800mm

  • Engine Power:55HP

  • Color:Gray

  • Transmission:Hydraulic Steering

  • Trademark:Dafeng King

  • Specification:ISO9001: 2008

  • Origin:Yanzhou City, Shandong Province, China

  • HS Code:84335100

Product Description

A. Wheel Self-propelled Wheat Combine Harvester

Modle: 4LZ-1.5

Price: $54400 /set

Qty'/40HQ: 2 sets

Delivery time: 21 days

Payment term: T/T or L/C

B. Advantage performance:

1. It is specialized for harvesting wheat

2. Adopt Hydraulic steering and runing control, and the Hydraulic control the header lifting

3.1800mm cutter width is suitable for blockette field

4. Double re-threshing rollers, the grain is very clean

5. Strong reels and and spring-tooth

Main Performance
Loss Rate ≤1.2%
Grain Broken Rate ≤1.0%
Impurities Rate ≤2.0%
Work reliability ≥93



Technical specification sheet
Type   Wheel full feed self-propelled
Model   4LZ-1.5
Cutting Width mm 1800
Feed Kg/s 1.5
Running speed Km/h 2.48-16
Diesel Engine Model   4L68
Power KW 40
Rotate Speed r/min 2600
Average Oil Consumption per Hectare Kg/hm² ≤27
Working Productivity Mu/H 4-6 (0.27-0.4Hec/H)
Total Weight kg 2800
Dimension
(L×W×H)
mm 5800
2400
3000
Ground Clearance mm 310
Header Reel Type   Spring-tined
Reel Diameter Mm Φ900
Reel Bat Piece 5
Cross auger Type   Screw auger, eccentric extensible link
Cross Auger Diameter mm Φ500
Clearance between Auger and Bed Plate mm 12-20
Cutter bar Stroked mm 76.2
Cutter bar Type   Domestic strandard II
Conveyer Type   Flat belt raked tine
Width mm 400
Threshing Drum Type   Transverse Axial Flow
Diameter mm Φ545 adjustable
Length mm 1350
Re-sthreshing Drum Type   Axial flow cutting plate
Diameter mm Φ190
Concave Type   Grid based
Angle (°) 236.8
Separation Area m² 1.38
Re-threshing Concave Type   Punch type
Separation Area m² 0.45
Sieves Type   Double sieves + fan + re-threshing
above sieve m² 0.76
bottom sieve m² 0.92
Fan Type   Low-pressure, volute
Diameter mm Φ346.8
Elevator Auger Diameter×Thread Pitch mm Φ120×116
Unloading type     mechanical
Tank capacity   m3 1
Chassis Type   4×2 wheeled
Front-wheel tread mm 1300-1200
two-stage adjustable
Trailing wheel tread mm 1290-1210two-stage adjustable
Gear box   3×2+1
Wheelbase mm 1985
Front-wheel Model   9.5-20
Trailing Wheel Model   6.0-16
Tire Pressure MPa Front wheel
0.28
Trailing wheel
0.36
Oil Tank Capacity L 65
Operator   1 Person
Qty'/40HC Sets 2
