Crawler Type Rice and Wheat Combine Harvester

Weifang Shengchuan Machinery Co.,Ltd | Updated: Jun 30, 2017



Crawler Type Rice and Wheat Combine Harvester Basic Info.



Model NO.:4LZ-2.0D



Type:Horizontal Cut Harvester



Application:Rice, Wheat, Rape



Power Source:Diesel



Drive Type:Gear Drive



Certification:ISO9001:2008



Color:Red



Crawler Type Rice and Wheat Combine Harvester Condition:New



Application Field:Agriculture



Colour:Red and White



Cutting Width:2000mm



Steering Type:Hydraulic Steering



Power:75HP(55kw)



Crawler Type Rice and Wheat Combine Harvester Product Description

    Favorable Advantages

1. 75HP diesel engine, 2 meters cutting width, Auto Transmission, high efficiency.
2. Double axial flow threshing cylinders and adjustable front & rear sieving plates ensure the grain more clean, less breakage and less loss.

3. Big width conveyer groove with innovated cutter bar lifting system can provide a more efficient feeding and a higher lifting level, convenient for working in paddy field and maintenance, and lower the noise and vibration.
4. Lower ground pressure, better for passing in paddy field.
5. Extremely strong Chassis; Excellent waterproof suspension wheel system; Easier turning & control with friction disc brake and special heavy-duty gearbox for hydraulic steering combine harvester.

ItemUnitSize

Structure Style/Track Self-Walking Full-Feed

Applicability For Crop (Physical Height)mmPaddy, wheat: 500-1200Cole:601-700

Power Motivekw/rpm55/2400

Productivity of Pure Working Hourhm2/hPaddy,wheat:0.2-0.47Cole:0.1-0.3

Fuel Oil Consumption per Hectarekg/hm2≤38≤30

Outline Sizes in Working State
(L×W×H)
mm4750×2350×2360Cole
5020×2450×2300


Structural WeightkgPaddy, wheat:2350Cole: 2450

Cutting Widthmm2000

Feed Volumekg/sPaddy, wheat:2.0Cole: 1.5

Minimum Gap of Off-Groundmm240

Style of Swerve/Hydraulic Style

Shift Modality/Automatic Mechanical Transmission +HST
Hydraulic Continuously Variable Transmission


Speed of Operation Forwardm/s0~2.88, 0~4.54, 0~7.56

Stroke of CuttermmII type

Auger Style of Cutting Table/Spiral Conveying

Outer Diameter of Auger of CuttingmmΦ470

Style of Reel/Eccentric Style

Diameter of ReelmmΦ900

No. of Plates of ReelPCS5

Conveyor Belt Style/Rake-Teeth Style

Threshing Roller Style/Tangential flow + Axial flow

Size of Threshing Roller(O.D. ×L)Front RollermmΦ540×650

Rear RollermmΦ540×1285
Concave Style/Grid Screen×2
Angle Range of Concave(°)227°
Fan Style/Centrifugal
Diameter of FanmmΦ328
Diameter of Grain Discharge augermmΦ123
Crew Distance of Grain Discharge augermm105



Crawler Type Rice and Wheat Combine Harvester.jpg
