Tillage Machine/Tiller/Subsoiler Mahcinery

Weifang Shengchuan Machinery Co.,Ltd | Updated: Mar 22, 2018



Tillage Machine/Tiller/Subsoiler Mahcinery Basic Info.



Model NO.:1PS-150/250/350



Tillage Machinery Type:Disc Plough



Application Field:Agriculture, Livestock, Aquaculture, Forestry



Farming Policy:Dry Cultivating Machinery



Tillage Machinery Power Source:Tractor



Operation:Continuous Running Operation, Soil Preparation Machinery



Traction Type:Traction



Tillage Machinery Certification:SGS



Color:Yellow



Price:Best



Quality:Best



Tillage Machinery Warranty:12 Month



Specification:ISO9001: 2000



Origin:China



HS Code:8432809000



Tillage Machine/Tiller/Subsoiler Mahcinery Product Description

    Subsoiler, subsoiler factory, subsoiler price, farm machinery
Warranty: 12 month
Subsoiler joint soil preparation machine
Matched tractor power: 120-280HP
Working width: 1.5-3.5m
Working depth: 500mm

1PS series subsoiler joint soil preparation machine is the subsoiling and ploughing work organically integrated together joint operating machinery, Can be completed once the soil deep loosening and breaking the soil surface, smooth operation. The subsoiler joint soil preparation machine is good performance of into the soil, Deep loosening after surface fluctuation is not obvious, aerates and fluff out the soil. After plowing groove forming ditch can keep soil moisture, improve the subsoiling on crop yield increase. The machine has the advantages of reasonable design, simple mechanism, easy installation and adjustment, application of hydraulic system and simplify the operation, control the tillage depth, time saving features

Model1PS-1501PS-2501PS-350

Working width(mm)
150025003500

Working depth(mm)
500500500

No. of tine(pc)
357

Overall(L*W*H)(mm)
1550x3100x16002550x3100x16003550x3100x1600
Weight(kg)900-9501050-11001200-1250

Matched power(hp)
> 120> 150> 180
Linkage3 point mounted


Tillage Machine/Tiller/Subsoiler Mahcinery.jpg
