Basic Info
Model NO.: 4s-120
Power Source: Diesel
Drive Type: Gear Drive
Portable Harvester Type: Self Propelling
Color: Red and Yellow
Application Field: Agriculture
Application: Rice, Wheat, Soybean, Rape Seeds and Other Granular Crops
Harvest method: Cutting
Transmission: Hard Shaft
Certification: SGS, ISO9001:2008, CE
Condition: New
Product Description
4LZ-3.0 Combine Harvester, is suitable for rice, wheat, rape seeds and other granular crops, its widder rubber track with teeth, it performance very good in water field.
This machine is easy for operation and maintence, it is a safety and energy-saving machine.
| Overall Dimension | Length×Width×Heights ( mm ): 4550×2350×2300 |
| Weight (kg) | 2700 |
| Feeding Capacity( kg/s ) | 3.0 |
| Harvesting Capacity(hm²/h): | 0.2-0.45 |
| Engine | Engine Model: 498BT/BZT/L; |
|
|
Rated Power ( kw/hp ): 65/88, 55/75 (Alternative) |
|
|
Type: Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel. Turbocharged Engine. |
| Driving System | Crawlers(mm): 90*48*400, or :90*48*450 or :90*48*500, , |
|
|
Minimum Ground Clearance (mm): 280 |
|
|
Type of Gearbox: Mechanism + HST(3F, 3R) |
| Cutting header | Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5 |
|
|
Cutting Bar Length ( mm ): 2000 |
|
|
Rape Seed Extension: Optional |
| Threshing & Separating | Threshing System: Spiked Tooth Axial Flow |
| & Cleaning System | Main Threshing Cylinder Size Diameter × Length ( mm ): 540×1285 |
|
|
Assistant Threshing Cylinder Size Diameter × Length ( mm ): 540×650 |
|
|
Vibrating Sieve: Adjustable sieve or Round hole sieve. |
|
|
Concave Sieve: Grid × 2 |
| Grain Storing | Option 1: Big Grain Tank with Unloading Auger, Capacity ( L ): 1600 |
|
|
Option 2: Small Tank Manual Operation. |
