1lz-3.6 Once-Cover Tillage Machine Working Width 3.6m Basic Info.
Model NO.:many
Type:Once-Over Tillage Machine
Application Field:Agriculture
Power Source:Tractor
Traction Type:Tractor
Tillage Machinery Certification:ISO9001
Color:Yellow
Tillage Machinery Specification:many
Origin:Shan Dong China
1lz-3.6 Once-Cover Tillage Machine Working Width 3.6m Product Description
Once-over tillage machine
The Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the field improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from three point six meters to 7.2m, it can be content with different customer's requirement.
Technical parameters:
| Type | 1LZ-3.6 | 1LZ-4.2 | 1LZ-5.4 | 1LZ-7.2 | ||
| Overall dimensions(mm) | L | 6600 | 6600 | 6600 | 7000 | |
| W | 3800 | 4400 | 5600 | 7500 | ||
| H | 1000 | 1000 | 1000 | 1000 | ||
| Max. Working width (m) | 3.6 | 4.2 | 5.4 | 7.2 | ||
| Working depth(mm) | 80-140 | 80-140 | 80-140 | 80-140 | ||
| No. Of disc(PC) | 42 | 50 | 64 | 84 | ||
| Disc of Type (mm) | 460×3 | 460×3 | 460×3 | 460×3 | ||
| Disc spacing(mm) | 170 | 170 | 170 | 170 | ||
| Weight(KG) | 2350 | 2680 | 3320 | 4360 | ||
| Productivity(Ha/h) | 2.28 | 2.66 | 3.33 | 4.44 | ||
| Linkage | Trailed Trailed |
|||||
| Trans. Clearance(mm) | ≥160 ≥160 |
|||||
| Matched power(Hp) | ≥65 | ≥80 | ≥100 | ≥120 | ||
