Power Tiller 1lz-4.2 Once-Over Tillage Machine Basic Info.
Model NO.:1LZ-4.2
Type:Once-Over Tillage Machine
Tillage Machinery Application Field:Fisheries, Forestry
Farming Policy:Mountain Machinery
Power Source:Tractor
Operation:Tractor, Tractor
Tillage Machinery Traction Type:Three Point Mounted
Certification:ISO9001
Color:Many
Specification:many
Origin:Shan Dong China
Power Tiller 1lz-4.2 Once-Over Tillage Machine Product Description
Once-over tillage machine
The Once-over tillage machine can complete the pulverize/Smash/Shatter , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the field improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from three point six meters to 7.2m, it can be content with different customer's requirement.
Power Tiller 1lz-4.2 Once-Over Tillage Machine Technical parameters:
| Type | 1LZ-3.6 | 1LZ-4.2 | 1LZ-5.4 | 1LZ-7.2 | ||
| Overall dimensions(mm) | L | 6600 | 6600 | 6600 | 7000 | |
| W | 3800 | 4400 | 5600 | 7500 | ||
| H | 1000 | 1000 | 1000 | 1000 | ||
| Max. Working width (m) | 3.6 | 4.2 | 5.4 | 7.2 | ||
| Working depth(mm) | 80-140 | 80-140 | 80-140 | 80-140 | ||
| No. Of disc(PC) | 42 | 50 | 64 | 84 | ||
| Disc of Type (mm) | 460×3 | 460×3 | 460×3 | 460×3 | ||
| Disc spacing(mm) | 170 | 170 | 170 | 170 | ||
| Weight(KG) | 2350 | 2680 | 3320 | 4360 | ||
| Productivity(Ha/h) | 2.28 | 2.66 | 3.33 | 4.44 | ||
| Linkage | Trailed Trailed |
|||||
| Trans. Clearance(mm) | ≥160 ≥160 |
|||||
| Matched power(Hp) | ≥65 | ≥80 | ≥100 | ≥120 | ||
