Tillage Cultivator/Tillage Machine Basic Info.
Model NO.:1LZ-3.6-9.3
Tillage Machinery Type:Disc Plough
Application Field:Agriculture, Livestock, Aquaculture, Forestry
Farming Policy:Dry Cultivating Machinery
Power Source:Tractor
Operation:Movable Operation, Soil Preparation Machinery
Tillage Machinery Traction Type:Traction
Drive Type:Chain Drive
Arbor Configuration:Vertical Shaft
Certification:SGS, ECE, EU, CE, ISO 9001: 2000
Tillage Machinery Color:Yellow
Model:1lz-3.6-9.3
Max. Working Width (M):3.6-9.3
Working Depth(Cm):8-14
No. of Disc(PC):42-108
Dia of Type:460X3
Disc Spacing(Mm):170
Productivity(Ha/H):2.28-4.44
Linkage:Trailed
Trans. Clearance(Mm):≥160
Matched Power(HP):80-220
Specification:CE, RoHS, SGS, GMP
Origin:Shandong Yucheng
HS Code:8433110000
Tillage Cultivator/Tillage Machine Product Description
Once-over tillage machine
The Once-over tillage machine can complete the pulverizer , soil transporting, soil mixing, leveling before sowing, repression, and can be directly prepared flat seedbed, they can improve the efficacy, reduce the cost. After stubble ploughing, the organic soil quality contents rise, soil structure improves, the yield improves.
The machine is suitable for growing out robust crop, and the same time you can Obtain greater benefits, All of these can be achieved depends on 1LZ series joint tillage machine, Working width from 3.6m to 7.2m, it can be content with different customer's requirement.
| Type | 1LZ-5.4 | 1LZ-7.2 | |
| Name | 84 | 84 | |
| Overall dimensions(MM) | L | 6600 | 7000 |
| W | 5600 | 7500 | |
| H | 1000 | 1000 | |
| Max. Working width (M) | 5.4 | 7.2 | |
| Working depth(CM) | 8-14 | 8-14 | |
| No. Of disc(PC) | 64 | 84 | |
| Dia of Type | 460×3 | 460×3 | |
| Disc spacing(MM) | 170 | 170 | |
| Weight(KG) | 3200 | 4600 | |
| Productivity(Ha/h) | 3.33 | 4.44 | |
| Linkage | Trailed | Trailed | |
| Trans. Clearance(MM) | ≥160 | ≥160 | |
| Matched power(Hp) | ≥100 | ≥120 | |
