Product Details
Key Specifications/Special Features:
Overview
NT-R16SN is 2U high 19" rack, 17 slots modular media converter chassis with redundant power and all hot swap plug design
It provides a high density media converter installation in enterprises or central offices
It provides 16 slots in front for media converter modular installation and 1 slot in back for managed card or cascading card
This not only reduces the number of tie wires and simplifies the structure, but also facilitates easy management and maintenance
Features:
Configuration of active/standby power supply ensures un-interruptible operation of the system
Provide two Redundant power supplies (220V AC and 48V DC), enabling the system can work under many operating environments
Supporting simultaneous operation of several modular type (modular type) media converters at different rates, which greatly improves system adaptability
Each card supports hot swapping
Compatible with 102SN, 103SN, 104SN series in a chassis
Specifications:
| Parameter | Specifications |
| Number of slots | 17 |
| Structure | 2U rack |
| Maximum power consumption | 65W |
| LED indication | Power (power supply) |
| Power configuration | Single power supply; or Dual power supply for redundant mode |
| Power output | 5V DC, 16A |
| Power supply | AC voltage: 110-265V AC, 50/60Hz DC voltage: 36-72V DC |
| Ripple | <100mV |
| Operating temperature | -10 to 55ºC |
| Operating humidity | 5-90% non-condensing |
| Storage temperature | -40 to 70ºC |
| Storage humidity | 5-90% non-condensing |
| Dimensions | (W) 423 x (D) 286 x (H) 91mm |
Primary Competitive Advantages:
Small Orders Accepted
Brand-name Parts
Country of Origin
Distributorships Offered
Electronic Link
Experienced Staff
Guarantee/Warranty
International Approvals
Military Specifications
Packaging
Price
Product Features
Product Performance
Quality Approvals
Reputation
Service
Main Export Markets:
Asia
Australasia
Central/South America
Eastern Europe
Mid East/Africa
North America
Western Europe
Payment Details:
Payment Terms:Telegraphic Transfer in Advance (Advance TT, T/T)
Minimum Order:1 Pieces
Delivery Details:
