Basic Info.
| Model NO.:MB-2M | Type:Multifunctional Pastoral Manage Machine |
| Application Field:Agriculture | Farming Policy:Dry Cultivating Machinery |
| Power Source:Diesel | Operation:Soil Preparation Machinery, Continuous Running Operation |
| Traction Type:Traction | Drive Type:Belt |
| Arbor Configuration:Horizontal Axis | Certification:SGS, CE |
| Color:Blue | Power:Gasoline Engine |
| Transmission:Belt Transmission | Trademark:MINGSIN |
| Specification:ISO9000 | Origin:Shandong, China |
| HS Code:84322900 |
Product Description
GT-4A tiller works in both pulling and driving type. It is mainly suitable for using in narrow land, terraced fields in mountain area, vegetable garden, orchard and greenhouse. It features compact construction, easy and flexible handling, light weight, reliable operation, convenient maintenance as well as good trafficability.
1. Its small-size, light-weight. Its horse power is strong and useful. Especially, it applies in narrow sections, terrace of mountain area, tea plantation, fruit woods, sheds and so on.
2. Lighted clutch, it also can work as over-load clutch. It can protect over load and use safely.
3. The handles can turn 360° Horizontally and regulate tap and down with four grades.
4. Its necessary farm machineries are all in readiness. With corresponding machineries, it can realize many functions, such as weeding. Breaking soil, making furrows, hilling soil, irrigating, spraying pesticide, ploughing.
5. Because the main enginer and vice enginer take fission quick link mechanism. It is very easy to adjust them.
6. The track and plough knife can be alternated breaclth with requirement.
| Model | Unit | GT-4 ( MD-4) | GT-4A ( MB- 2M ) |
| Overall dimensions (L*W*H) | mm | 1570*600*980 | |
| PTO speed | r/min. | 1511 | |
| Overall dimensions (L*W*H) | mm | 1000x400x970 | |
| Net weight | kg | 115 | 95 |
| Gross weight (with packing) | kg | 125 | 105 |
| Max. tilling width | mm | 840 | |
| Max. tilling depth | mm | 18 | |
| Clutch |
|
Tension pulley | |
| Driving wheel |
|
4.00-7 | |
| Ground clearance | mm | 85 | |
| Wheel tread | mm | 350-600 (adjustable) | |
| Tyre inflation pressure | kPa | 100-120 (in the field) 160-180 (for transportation) | |
| Transmission |
|
(1+1) ×2 compound type with spur gears | |
| Speed | km/h. | (I) 4.457, (II) 7.485, (RI )3.13, (RII) 5.307 | |
| Main drive |
|
Two pcs V-belt (B1270) | |
| Transmission oil capacity | L | 1.5 | |
| Working speed | m/s | 0.25 | |
| Rotary speed of driving shaft | r/min. | 85 (high spped)/50 (low speed) | |
| Trailer rated load | kg | 300 | |
| Engine | Model | 170F | 168FA-2 |
| Engine type |
|
Water cooled, 4-stroke, single cylinder, horizontal. |
OHV 25, air cooled, 4-stroke, single cylinder |
| Max. output | hp | 4.4 | 6.5 |
| Max. fuel consumption | g/kw.h | 289.7 | 395 |
| Rotary speed of engine | r/min. | 2600 | 2000 (after reduction) |
