7-inch Field Camera Monitor with HD-SDI, HDMI, YPbPr and AV for Film/TV/Video Shooting

Functions:

• F1-F4, 4 user-definable buttons, default functions:

  • F1: peaking filter

  • F2: false colors

  • F3: exposure

  • F4: histogram

• Others:

  • Cameras, center markers, pixel-to-pixel, color bars, screenmarkers, aspect ratio, check field, understand/over scan, freezeinput, H/V delay, 4x zoom, picture-in-picture, image flip

Parameters:

• Panel size: 7-inch TFT LCD (16:9)

• Resolution: 1,024 x 600, up to 1,920 x 1,080 pixels

• Brightness: 250cd/m²

• Contrast: 800:1

• Viewing angle: 160/150°(H/V)

• Input voltages: 6.5 to 24V DC (XLR DC connection)

• Input signal: HDMI, YPbPr, AV, HD-SDI (optional)

• Current: 650mA

• Standby current: 50mA

• Power consumption: 7.8W

• Sizes (L x W x D):

  • 194.5 x 150 x 38.5mm

  • 194.5 x 150 x 48.5mm (with cover closed)

  • 194.5 x 150 x 158.5mm (with cover open)

Accessories:

• Flexible folding sunshade cover: 1 piece

• Battery plate (F970/QM91D): 2 pieces

• DC adapter: 1 piece

• HDMI A/C cable: 1 piece

• Manual: 1 copy

• Battery plate DU21 (optional): 1 piece

• V-mount battery plate (optional): 1 piece

• Anton baker mounts battery plate (optional): 1 piece

• Li-ion DV battery (optional): 1 piece
