7-inch Professional HDMI Field Director Monitor with Auxiliary Focus Function

Specifications:

• 7-inch diagonal TFT LCD

• Resolution: 1,024 x 600, supports 1,920 x 1,440

• Horizontal frequencies: 30 to 60kHz

• Vertical frequencies: 60 to 75Hz

• Dot pitch: 0.05 (W) x 0.15mm (H)

• Aspect ratio: 16:9

• Contrast: 700:1

• LCD brightness: 250cd/m²

• Response time: 10ms

• Viewing angle: 75/75° (L/R), 70/75° (U/D)

• Backlight: LED

• Input signal: HDMI, YPbPr, Audio and Video

• Output signal: HDMI (optional), Video

• Supported formats for HDMI/YPbPr: 480i, 480p, 576i, 576p, 720p,1080i and 1080p

• Color signal type: PAL-4.43/NTSC-3.58

• Output speaker consumption: ≥1W/8©

• Input voltages: DC 6 to 14V

• Power consumption: ≤7W

• Operating temperatures: -20 to 55°C

• Storage temperatures: -30 to 65°C

• Weight: 469g

• Dimensions (L x W x D): 188.5 x 134 x 42.5mm

Advance features:

• Peaking filter (focus assist)

• 5D-II camera mode

• Check field: red, green, blue, monochrome and color

• Underscan/over-scan

• Center marker

• Screen markers: 80%, 85%, 90%, 93% and 96%

• Image flip (U/D, L/R)

• Brightness, contrast ratio, tint, saturation and colortemperature are adjustable

• 1 earphones jack in front panel in addition to a built-inspeaker

• Variety of user-replaceable battery plate (Sony V-mount,Panasonic Anton, DV battery)

• Multiple mounting methods to view under different angles

• High brightness/contrast and dizzy-proof monitor with sunshade, to see clearly under sunshine

Accessories:

• Mini HDMI cable

• Hot shoe mount

• Sony F970 battery plate

• Sun shade (optional)
