Self-Propelled Peanut Combine Harvester 4hb-2A Basic Info
Model NO.: 4HB-2A
Application: Tubers, Peanut
Reaper Harvest method: Mining
Transmission: Soft Shaft
Certification: QS, SGS, ISO9001:2008, CE
Condition: New
Origin: China
Type: Horizontal Cut Harvester
Power Source: Tractor
Reaper Drive Type: Gear Drive
Portable Harvester Type: Backpack Type
Color: Red
Reaper Application Field: Agriculture
Specification: CE, ISO
Self-Propelled Peanut Combine Harvester 4hb-2A Product Description
Self-propelled Peanut Combine Harvester 4HB-2A
1. Hold the seedling, mining, transportation, picking combine harvester systems: practical, low loss.
2. The difference between the relative half-feed roller picking system: low power consumption, crashed rate close to zero, high net picking rate, to ensure a seedling rate of complete in order to facilitate recycling of seedlings.
3. By consist of soil shaker, fans, vibrating screen, rubbing earthenware and hollow rotating sieve chain to have the efficient cleaning system: High cleaning rate.
4. Wheeled travel system: self-propelled, self-transfered, light soil compaction, to ensure easy peanut drop recycling and reproduction.
5. High performance to be used for most of the country dry crop patterns and soil condidtions.
Self-Propelled Peanut Combine Harvester 4hb-2A Technical Parameters
| Model | 4HB-2A |
| Power Matched | 30hp, 3-cylinder diesel engine |
| Structure Type | Suspension |
| Mining Depth | 100-200mm |
| Working Width | 600mm |
| Working Efficiency | 0.15 - 0.25ha./hr. |
| Overall Dimension(LxWxH) | 3970x1800x2550mm |
| Structure Weight | 1750kg |
| Total Loss Rate | ≤ 1% |
| Impurities Rate | ≤ 3% |
| Crashed Rate | ≤ 1% |
| Cleaning Rate | ≥ 96% |
| Seedling Rate of Complete | ≥ 98% |
