4lz-2.0 4lz-3.0 Agricultural Combine Harvester Basic Info
Model NO.: 4LZ-3.0
Application: Rice, Wheat
Reaper Harvest method: Picking
Transmission: Soft Shaft
Certification: ISO9001:2008
Condition: New
Reaper Undercarriage: Ribber Track Type
Specification: ISO9001
HS Code: 8433510090
Type: Horizontal Cut Harvester
Reaper Power Source: Diesel
Drive Type: Vee belt
Portable Harvester Type: Backpack Type
Color: Red
Reaper Application Field: Agriculture
Origin: Shandong, China
4lz-2.0 4lz-3.0 Agricultural Combine Harvester Product Description
Main advantages:
1. Compact structure, excellent performance, Low ground pressure, high performance in wet or mud land
2. High threshing ability, low broken rate. Low lost rate
3. Thorough clearance with double shakers for re-threshing
4. Famous brand engine with large power and stable performance
| ltem Model | 4LZ-3.0 |
| Cutting width | 2580mm |
| Working capacity | 0.47 hec/h |
| Fuel consumption | 8-10L/h |
| engine horsepower | 60KW(82HP) |
| Weigh(kg) | 3200 |
| Track | 400mm*90mm*48 |
| Dimensions at work,LxWxH(mm) | 5280x2960x3000 |
| Total losses(%) | Rice≤3.0 ,Wheat≤1.5 |
| lmpurity rate(% | ≤2.0 |
| Breakage rate(%) | ≤1.5 |
| Reliability(%) | ≥93 |
| Feed rate(kg/s) | 3.0 |
| Ground pressure(kpa) | ≤24 |
| Min.ground clearance(mm) | ≥200 |
| grain Tank | 1.3m3 (storage 700kg rice) |
| Cleaning type | Double sieves + blower + re-thresher |
| Grain unloading method | Sacked & Auto unloading |
| Shipment | 2sets/40'HQ |
