4lz-2.0 Rice Wheat Combine Harvester Basic Info
Model NO.: 4LZ-2.0
Reaper Application: Rice, Corn, Wheat, Soybean
Harvest method: Vibration fall
Transmission: Hard Shaft
Reaper Color: Red
Application Field: Agriculture, Livestock, Aquaculture, Forestry
Specification: CE, ISO
Type: Combine Harvester
Reaper Power Source: Tractor
Drive Type: Gear Drive
Reaper Certification: QS, SGS, ISO9001:2008, CE
Condition: New
Origin: China
4lz-2.0 Rice Wheat Combine Harvester Product Description
Favorable Performance:
1. 400mm of caterpillar belt to protect falling; 1150mm of wide track; move smoothly.
2. Good threshing ability, low broken rate, low entrainment loss.
3. Optimized threshing and deaning mechanism with double shakers of re-threshing.
4. Name brand motors with great power and stable performance.
5. Great transmission and torque and swerve agilely.
4LZ pedrail self-propelled rice and wheat combine harvester cut stalk and separate from grains, equipment with Name brand motors with great power and stable performance, Big gear box with great transmission and torque and swerve agilely. Compact structure, Flexible operation and easy to maintainence. It is suitable for harvesting in paddy field or glebe in plains, mountainous area and hills.
4lz-2.0 Rice Wheat Combine Harvester Main technical specifications :
| Model | 4LZ-2.0 |
|
| Total loss rate | rice≤3.0% & wheat≤1.2% | |
| Impurity rate | rice≤2.0% & wheat≤2.0% | |
| Breakage rate | rice≤1.5% & wheat≤1.0% | |
| Using reliability | ≥95 | |
| Type | Track self-propelled | |
| Harvesting width | 1800/2200/2360mm | |
| Feed | 2.0kg/s | |
| Working Productivity | 0.2-0.5 hm2/h | |
|
Engine |
Type |
4102/4105 |
| power | 48KW /(55Kw) | |
| Rotate speed | 2600 r/min /(2400) | |
| Gear box | (6+2)shift | |
| Diesel tank | 65 L | |
| Fuel consumption per hectare | ≤30Kg/ha. | |
| Track Width | 350*90*48 / 400×90×48 | |
| Ground presssure | ≤24 KPa | |
| Ground clearance | 230mm | |
| Steering | Hydraulic | |
| Grain tank | 1 m3 | |
| Grain unloading method | sacked | |
| Weight | Sunshade |
2800kg |
| Cabin | 3000Kg | |
| Dimension (L×W×H) | 5010×2360 ×2870 mm | |
