4lz-2.0z (4.0Z) Rice and Wheat Combine Harvester Basic Info.
Model NO.:4LZ-2.0Z(4.0Z)
Type:Horizontal Cut Harvester
Application:Rice, Corn, Wheat, Soybean, Straw
Reaper Power Source:Diesel
Harvest method:Cutting
Drive Type:Vee belt
Reaper Transmission:Hard Shaft
Portable Harvester Type:Combine
Certification:ISO9001:2008
Reaper Color:Green
Condition:New
Application Field:Agriculture, Livestock, Aquaculture
Reaper Feeding Capacity:4.0
Origin:China
HS Code:84335100
4lz-2.0z (4.0Z) Rice and Wheat Combine Harvester Product Description
4LZ-2.0Z(4.0Z) combine with excellent performance in different crops and different field conditions,the machine is easy for operation and maintenance, it is a safety and energy-saving machine.
| 4LZ-2.0Z(4.0Z) COMBINE HARVESTER | |
| Model: | 4LZ-4.0Z Combine Harvester |
| Type: | Full-feed, Track Combine |
| Application: | Grain, Wheat, Rape Seed. |
| Feature | Featured with 37cc HST, 60 gearbox, wider rubber track, and bigger storing tank 1200L, bigger |
|
|
feeding capacity, and higher output. |
| Quality System: | Production Plant Accredited to GB/T 19001-2008 / ISO9001 :2008. |
|
| |
| Specification: |
|
| Overall Dimension | Length×Width×Heights ( mm ): 5100×2600×2450 |
| Weight (kg) | 3000 |
| Feeding Capacity( kg/s ) | 4 |
| Harvesting Capacity(hm2/h): | 0.4-0.75 |
| Engine | Engine Model: 498BT/BZT/L; 4C6-88M22 |
|
|
Rated Power ( kw/hp ): 65kw/88hp |
|
|
Engine Type: Water-Cooled, 4-Cylinder, DI-Injection, Vertical Diesel. Turbocharged Engine. |
|
|
Rated Rotation Speed (r/min) : 2400 |
|
|
Fuel Tank Capacity ( l ): 70 |
| Driving System | Crawlers(mm): 90×51×450 |
|
|
Crawler Steering Radius ( mm ): left turn 2850; right turn 2850 |
|
|
Minimum Ground Clearance (mm): 280 |
|
|
Type of Gearbox: Hydraulic type + HST(3F, 3R) |
|
|
Theoretical Operating Speed ( km/h ): 2~4 |
|
|
Type of Brake: By Foot. |
|
|
Steering: Clutch and Brake. |
| Cutting header | Pickup Reel: Type:Tooth ( off-centre ); Diameter( mm ): 900; Nos: 5 |
|
|
Height Adjustment: Hydaulics. |
|
|
Cutting Bar Length ( mm ): 2028/ 2228 |
|
|
Type of Cutting Bar Auger: Screw Conveying. |
|
|
Type of Blade: V Type / Left and Right. |
|
|
Rape Seed Extension: Optional |
| Threshing & Separating | Threshing System: Spiked Tooth Axial Flow(Single-big-threshing cylinder) |
| & Cleaning System | Threshing Cylinder Size Diameter × Length ( mm ): 620×1700 |
|
|
Reshresher: Blade Rotation. |
|
|
Vibrating Sieve: Adjustable Sieve+ Meshing Sieve |
|
|
Fan: Type: Swirl; Diameter( mm ): 405; Nos: 4 |
| Grain Storing | Option 1: Grain Tank with Unloading Auger, Capacity ( l ): 1200 |
|
|
Option 2: Manual Operation. |
